【产品名称】：BY系列包衣机（糖衣机）
BY系列
包衣机（糖衣机）
主要用途
本机用以制药，食品行业为片剂，丸剂包裹糖衣，也可以用作滚炒豆，果品类成熟之用。其特点是糖衣锅的倾斜角度可调，锅下可旋转电炉、煤气等直接加热设备。随着附单独的电热式鼓风机，出风管深入锅内可作加热或吹冷，热量也可以调节。
MAIN PUROSE
This machine is used for pharmaceutical, food industry for tablets, pills wrapped sugar, can also be used as a rolling Chaodou, with mature fruits. The utility model is characterized in that the tilt angle of the sugar coated pot can be adjusted, and the direct heating equipment such as electric stove and gas can be rotated under the pot. With the separate electric heating type blower, the air outlet pipe can be heated or blown in the pot.
主要特点
♦可配变频调整器；
♦可配除尘系统；
♦可做全封闭形式，配喷枪系统，达到GMP要求。
MAIN FEATURE The optional variable frequency regulator;
With the dust removal system;
Do the full closed form, with the gun system, meet the requirements of GMP.
技术参数 TECHNICAL PARAMETERS
|
型号Model |
BY-300 |
BY-400 |
BY-600 |
BY-800 |
BY-1000 |
BY-1250 |
|
糖衣锅直径Sugar coating pot diameter（mm） |
300 |
400 |
600 |
800 |
1000 |
1250 |
|
糖衣锅转速 Sugar coating pot rotation speed(r/min) |
46 |
46 |
40 |
32 |
32 |
30 |
|
主机功率Main power（kw） |
0.37 |
0.55 |
0.55 |
1.1 |
1.5 |
2.2 |
|
电热丝功率Electric wire power（w） |
500 |
500 |
800 |
1000 |
1000 |
1000 |
|
鼓风机功率Blower power（w） |
40 |
40 |
60 |
250 |
250 |
250 |
|
生产能力Production capacity（kg/次） |
2 |
5 |
15 |
30~50 |
50~70 |
90~150 |
|
机器重量Machine weight（kg） |
65 |
70 |
120 |
240 |
250 |
280 |
|
外形尺寸Overall size（mm） |
485×585×766 |
485×585×810 |
700×540×1300 |
925×900×1500 |
1100×1100×1600 |
1200×1250×1630 |
|
外加热功率External heating power（w） |
500 |
500 |
600 |
1000×2 |
1000×2 |
1000×2 |
