【产品名称】：ZPY124旋转式压片机

ZPW100系列

自动旋转式压片机

主要特点

♦外围罩壳为全封闭，材料采用不锈钢，内部台面用不锈钢材料，能保持表面光泽及防止交叉污染，符合MGP要求。♦装有透明防护罩可以清楚的观察压片的状态。侧面板能全部打开，易于清洗和保养。♦所有控制器和操作件均布局合理，采用人机界面变频调速装置进行电气调速和反逆转。♦操作方便，转动平稳，安全准确。实行机电一体化，采用触摸屏PLC控制及操作。♦传动系统密闭在机器主体下方油箱中，是安全风隔的独立部件，亦不会互相污染，易散热且耐磨。♦机器装有吸尘装置，能将室内飞扬的粉尘吸收干净。♦本机压力大，能适应各类大、小片及难成型片剂的生产，是片剂生产ZUI理想的设备。

MAIN FEATURE

♦The external machine is fully enclosed, made of stainless steel and internal surfaces are made of stainless steel material, can keep the surface gloss and prevent cross contamination, in line with the MGP requirements.

♦The transparent protective cover can clearly observe the press condition. ♦The side panel can be opened completely, easy to clean and maintain.

♦All the controllers and operating parts are reasonable layout, man-machine interface adopts variable frequency variable speed device and anti reverse.

The operation is convenient, smooth rotation, safe and accurate. ♦Mechanical and electrical integration, the use of touch screen PLC control and operation.

♦The transmission system is sealed in the machine body below the tank, is the independent component of security isolation, nor mutual pollution, easy to heat and wear.

♦The machine is provided with a suction device, the absorption of a clean indoor flying dust.



型号 Model	ZP-23	ZP-25	ZP-27
转台冲模数Turret punch quantity（Sets）	23	25	27
ZUI大工作压力Max.Working pressure(kn)	100	100	100
ZUI大压片直径Max.tablet diameter(mm)	35	32	30
ZUI大压片厚度Max.tablet thickness(mm)	15	15	15
ZUI大充填深度Max.filling depth(mm)	30	30	30
ZUI大压片产量Max.table pressing output(Pc/h)	69000	75000	81000
转台工作直径Turntable working diameter（mm）	445	445	445
转台转速Turret speed(r/min)	10-25	10-25	10-25
中模直径Middle mold diameter(mm)	52	52	52
中模高度Middle mold height（mm）	38	38	38
上、下冲杆直径Upper and lower punch diameters(mm)	45	45	45
上冲杆长度Upper punch length(mm)	175	175	175
下冲杆长度Lower punch length(mm)	180	180	180
外形尺寸Overall size(mm)	1000×1250×1900	1000×1250×1900	1000×1250×1900
电压Voltage（V）	380	380	380
配用电动机型号Motor model	YU132M4A	YU132M4A	YU132M4A
电机功率Motor power（kw）	7.5	7.5	7.5
主机重量Machine weight(kg)	3200	3200	3200
